TIF100 10055-50 Silicone Thermal Pad Blue Wholesale Silicone Rubber Thermal Insulation Pad Thermal Silicone Pad With Adhesive For 5G Base Stations
The TIF®100 10055-50 Series a well-balanced,general-purpose thermal pad. It offers excellent thermal conductivity and moderate hardness. This balanced design provides both good surface conformity and excellent ease of use, making it capable of effectively transferring heat and providing basic physical protection for a wide range of electronic components. It is an ideal choice for addressing medium to high power heat dissipation needs, achieving the best balance between cost and performance.
Features:
> Good thermal conductivity: 10.0 W/mK
> Good flexibility and fillability
> Self-adhesive without the need for additional surface adhesives
> Good insulation performance
Applications
> Al Servers
> Semiconductor Packaging
> Low-Altitude Aircraft
> Optical Communication Products
> 5G Base Stations
> Power tools
> Network communication products
> Electric vehicle batteries
> Computer CPU/GPU Cooling
> New energy vehicle power systems
| Typical Properties of TIF®100 10055-50 Series |
| Property | Value | Test method |
| Color | Pink | Visual |
| Construction & Compostion | Ceramic filled silicone elastomer | ****** |
| Density(g/cm³) | 3.4 | ASTM D792 |
| Thickness Range(inch/mm) | 0.020~0.030 (0.50~0.75) | 0.040~0.200 (1.0~5.0) | ASTM D374 |
| Hardness | 70 Shore 00 | 55 Shore 00 | ASTM 2240 |
| Recommended Operating Temperature | -40 to 200℃ | *** |
| Breakdown Voltage(V/mm) | ≥5500 | ASTM D149 |
| Dielectric Constant | 8.5 MHz | ASTM D150 |
| Volume Resistivity | ＞1.0X1014 Ohm-meter | ASTM D257 |
| Flame rating | V-0 | UL 94 (E331100) |
| Thermal conductivity | 10.0 W/m-K | ASTM D5470 |
| 10.0 W/m-K | ISO22007 |
Product Specifications
Standard Thickness: 0.02"(0.50 mm)-0.20" (5.00 mm) with increments of 0.01 inch (0.25 mm).
Standard Size: 16"×16" (406 mm ×406 mm)
Component Codes:
Coating Options: NS1 (Non-adhesive treatment),
DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).
The TIF® series is available in custom shapes and various forms.
For other thicknesses or more information, please contact us.
Packaging Details & Lead time
The packaging of thermal pad
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated
